Standard Equipment:
- Dismountable gantry in 3 elements for indoor or outdoor use
- 4 swivel polyamide wheels
- Welded construction (welders certified NF EN ISO 9606-1: 2017)
- Rolling gantry under load on smooth ground or clean slab
- Hoist speed limited to 16 m/min for lifting and 10 m/min for direction
- Very easy gantry movement / easy empty movement
- Packaging on pallets and shrink wrap film
Optional Equipment:
- Swivel polyamide wheels equipped with brakes
- Lockable switch
- Cable reel
- Power supply line
- Dimensions adapted on request
- Specific treatment (GALVANIZATION, etc.)
- Calculation note
Manufactured in accordance with the Machinery Directive 2006/42/EC
- Marking: WLL, EC, Serial number, year of manufacture
- Temperature range: From -10° up to +40°
- Finish: Yellow Rust-proof paint (RAL 1028)
- Note: Can be moved while loaded on flat, smooth and clean surfaces
- Warning: Do not pull with a motorised device
- Safety factor: 4:1
