Connecting Link Crosby A-1337

Crosby

LOK-A-LOY Connecting Link

Features:

  • Suitable for use with both Grade 80 and Grade 100 chain.
  • Individually Proof Tested at 2-1/2 times Working Load Limit with certification.
  • Locking system that provides for simple assembly and disassembly - no special tools needed.
  • 25% stronger than Grade 80.
  • Material: Forged Alloy Steel - Quenched and Tempered
  • Marking: Code and grade.
  • Finish: Painted.
  • Safety factor: 4:1
  • Grade: 10
Connecting link Platinum A-1337
Connecting link Platinum A-1337
Select a row from the table below, then click the add to quote button
Part Code WLL
ton		 Chain
mm		 A
mm		 B
mm		 C
mm		 D
mm		 E
mm		 F
mm		 Weight
kg		 CAD
11.06101510 2 7 9,7 49,3 48,3 20,6 17,5 14,5 0,12 -
154005 2,5 8 9,40 59,7 52,6 25,1 18,3 16,3 0,16 -
153995 4 10 12,2 68,6 62,7 28,4 22,9 19,8 0,34 -
154009 6,8 13 17,3 87,6 84,1 36,6 28,4 24,6 0,73 -
154012 10,2 16 20,6 105 99,1 43,7 34,3 29,0 1,3 -
154010 16 20 23,6 118 118 53,1 40,4 32,5 2,26 -
154011 19,4 22 26,9 140 143 58,7 50,0 36,6 3,41 -
11.061015181 27,1 25 31,0 152 157 63,5 56,4 47,8 5 -
11.061015181 41 32 38,1 189 194 78,5 64,3 55,6 9,25 -
