• Not for lifting
  • Material: polyamide, polyester or polypropylene
Select a row from the table below, then click the add to quote button
Part Code Diameter
mm
Min. breaking force
kN
Length
m
Rope Weight
kg/100m
CAD
12.03PAE010WEC20P 1 0.49 200 Polyamide 0.09
12.03PAE015WEC20P 1.5 0.64 200 Polyamide 0.14
12.03PAE020WEC20P 2 0.88 200 Polyamide 0.17
12.03PPE020WEC20P 2 0.44 Polypropylene 0.19
12.03PES020WEC20P 2 1.03 200 Polyester 0.27
12.03PAE025WEC20P 2.5 1.27 200 Polyamide 0.27
12.03PES025WEC20P 2.5 1.67 200 Polyester 0.48
12.03PPE030WEC20P 3 1.08 Polypropylene 0.4
12.03PAE030WEC20P 3 2.3 200 Polyamide 0.45
12.03PES030WEC20P 3 2.65 200 Polyester 0.59
12.03PAE035WEC20P 3.5 2.75 200 Polyamide 0.63
12.03PPE040WEC10P 4 1.47 Polypropylene 0.7
12.03PAE040WEC10P 4 3.14 100 Polyamide 0.75
12.03PES040WEC10P 4 3.24 100 Polyester 1.05
12.03PPE050WEC10P 5 2.25 Polypropylene 0.95
12.03PAE050WEC10P 5 4.71 100 Polyamide 1.23
12.03PES050WEC10P 5 4.71 100 Polyester 1.75
12.03PPE060WEC10P 6 2.94 Polypropylene 1.35
12.03PAE060WEC10P 6 6.27 100 Polyamide 1.64
12.03PES060WEC10P 6 7.06 100 Polyester 2.9
12.03PPE080WEC10P 8 5.64 Polypropylene 2.9
12.03PAE080WEC10P 8 11.76 100 Polyamide 3.23
12.03PES080WEC10P 8 10.78 100 Polyester 4.2
12.03PPE100WEC10P 10 8.33 Polypropylene 4.35
12.03PAE100WEC10P 10 19.61 100 Polyamide 5.25
12.03PES100WEC10P 10 15 100 Polyester 5.7
12.03PPE120WEC10P 12 9.8 Polypropylene 5.85
12.03PAE120WEC10P 12 27.45 100 Polyamide 7.4
12.03PES120WEC10P 12 21.57 100 Polyester 9.2
12.03PAE140WEC10P 14 33.33 100 Polyamide 10
12.03PES140WEC10P 14 26.96 100 Polyester 11.5
12.03PAE160WEC10P 16 41.18 100 Polyamide 13
12.03PAE180WEC10P 18 51.96 100 Polyamide 18
12.03PPE025WEC20P 0.69 Polypropylene 0.23
