Quick Link- Stainless, AISI 316 quick link

Home / Quick Link- Stainless

General: For use to connect or lengthen grade 2 stainless chain.

Finish: Stainless, AISI 316.
Warning: Not for lifting.

Quicklink_SS

Rzm_e_225mm

Select a row from the table below, then click the add to quote button

Part Code	Diameter mm	A mm	C mm	L mm	D mm	Weight kg/100pc
11.5612010900	4	11	5	31	4	1.4
11.5612011000	5	13	6	38	5	2.2
11.5612011100	6	14	7	45	6	3.6
11.5612011300	8	18	10	60	8	7.8
11.5612011500	10	20	12	69	10	14
11.5612011502	12	25	15	83	12	20

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.

Get CAD

Download
