Lever hoist YaleERGO 360 UT is optimized for overhead line construction. Its automatic safety gear increases safety in use. The ergonomic design and the integrated handle allow efficient working in any angle, for lifting and pulling applications.

  • Automatic safety gear
  • Corrosion protection
  • Handle integrated to the lever
  • Easy maintenance & inspection

Options :

  • Chain stopper
  • Load limiter (overload protection)
  • Marking: According to standard
  • Standard: EN 1808
  • Safety factor: 4:1
Select a row from the table below, then click the add to quote button
Part Code WLL
ton
Lifting height
m
Number of falls Model Lift with one full lever turn
mm
Handle pull at WLL
daN
Chain dimensions d x p
mm
Weight
kg
CAD
16.20192069625 1.5 1.5 1 YaleERGO 360 UT 1500 21.7 26.5 7.1 x 21 9.8
16.20192069671 3 1.5 1 YaleERGO 360 UT 3000 20.1 36 10 x 28 18.1
16.20192071416 6 1.5 2 YaleERGO 360 UT 6000 10.1 38 10 x 28 29.8
