The Ropeblock closed spelter socket CSS designed with mechanical values (Charpy-V > 42 joule / - 20° C) for though and low temperature use.
All sockets have a 100% efficency on the MBL of the steel wire rope but are limited to the MBL of the socket.
The CSS sockets are Type Approved by DNV and Lloyd’s Register.
CSS 296 until CSS 201 only available with hot dipped galvanized finish.
- Material: Quenched and tempered cast steel.
- Marking: CE-marked
- Temperature range: - 40°C to + 110°C - Use at higher temperatures possible with reduction of WLL.
- Finish: Hot dipped Galvanized (G) or painted blue (P).
