Eye Hook Crosby S-1316, Type SHUR-LOC

Crosby
  • 25% stronger than Grade 80
  • Individually Proof tested to 2-1/2 times the Working Load Limit with certification.
  • Recessed trigger design is flush with the hook body, protecting the trigger from potential damage.
  • Easy to operate with enlarged thumb access.
  • Positive Lock Latch is Self-Locking when hook is loaded.
  • Eye style is designed with "Engineered Flat" to connect to S-1325 chain coupler.
  • Suitable  for use with Grade 100 and Grade 80 chain.
  • The SHUR-LOCK hook, if properly installed and locked , can be used for personnel lifting applications and meets the intent of OSHA Rule 1926. 1431 (g)(1)(i)(A) and 1926. 1501(g)(4)(iv)(B).
  • Fatigue rated at 1-1/2 times the Working Load Limit at 20,000 cycles.



  • Material: Forged Alloy steel - Quenched and Tempered.
  • Warning: Not to be heat-treated.
  • Safety factor: 4:1.
  • Grade: 10
Eye hook Platinum S-1316
Eye hook Platinum S-1316
Eye hook Platinum S-1316_drawing
Select a row from the table below, then click the add to quote button
Part Code WLL
ton		 Chain
mm		 A
mm		 C
mm		 D
mm		 E
mm		 F
mm		 H
mm		 J
mm		 L
mm		 AA
mm		 Weight
kg		 CAD
154061 1.45 6 19,8 100 20,1 66,0 17,0 7,87 16,0 29,5 38,1 0.39
154062 2.6 7-8 27,4 135 27,9 88,9 22,1 9,91 20,6 37,6 51,0 0.82
154063 4 10 33,0 167 29,7 112 27,9 12,9 23,9 46,5 63,5 1.54
154064 6.8 13 41,9 209 42,4 139 32,0 17,0 29,5 56,4 76,2 2.72
154065 10.3 16 55,9 256 51,8 167 38,1 22,1 38,1 67,3 89,0 6.85
154066 16 18-20 66,0 274 56,4 197 51,1 22,1 51,6 89,4 - 8.62
154067 19.4 22 72,9 317 62,2 222 57,7 24,9 55,9 97,3 - 12.7
154068 27.1 26 80 371 81,5 251 62,5 32,0 68,1 104 - 22.5

Download CAD

Download CAD by choosing the desired product from the table above and the format from the menu below. Click "Get CAD" and after the load reaches 100% you can click on the download icon to download it. Please note that CAD drawings are only available if the icon at the right side of the table above is colored and not grayed out.
