Aluminium Cylinder HAC H

- Max. working pressure: 720 bar/ 72 Mpa
- Acting type: double
- Return type: hydraulic
- A range of more than 24 models with different tonnages and stroke lengths
- Duo Power Ring; seal and bearing for long life span
- Special coated Plunger with a hardened anodised layer
- XL Saddle+ protects the plunger and limits eccentric loads
- Almost all cylinders have a handle

Standard supplied with:
- High Flow female coupler A 118
- Flat saddle

Available on request:
- Cylinders manufactured in conformity with customer specifications
- Collar thread
- Base mounting holes
- Steel plate for protection of the cylinder bottom

Additional information:
Just as powerful as, though 50% lighter than its steel equivalent. This makes it easier and safer for a single user to lift higher tonnages. Aluminium cylinders offer an easy to handle alternative to steel. They should last a lifetime of use in average heavy duty lifting applications. However, aluminium cylinders should NOT be used in high cycle applications.
Aluminium cylinders obtained from Holmatro are designed to safely withstand up to 5,000 cycles at their maximum working pressure.

  • Material: Aluminium
