This hook is positioning device and is not intended to rotate under load.
Fatigue rated to 20,000 cycles at 1.5 times the WLL.
Proof Load tested at 2.5 times the WLL with certification for each batch manufactured.
Magnaflux crack detection is performed 100% on each batch.
With Brass Bushing.

  • Material: Quenched and Tempered Alloy Steel
  • Marking: According to standard, Size, grade, manufacturer ID, traceability.
  • Temperature range: -40ºC up to +200°C (without reduction in WLL).
  • Finish: Red painted
  • Standard: EN 1677-3
  • Safety factor: 4:1
  • Grade: 8
Select a row from the table below, then click the add to quote button
Part Code WLL
ton
Grade 80 Chain, 1-leg
mm
A
mm
B
mm
D
mm
H
mm
K
mm
P
mm
T
mm
Weight
kg
CAD
167083 1.12 6 31 22 12 19 149 29 15 0.7
165371 2 7, 8 36 29 14 24 186 34 20 1.2
165372 3.15 10 40 34 16 30 220 44 26 2
165373 5.3 13 46 43 22 39 267 52 30 4.2
165374 8 16 60 50 24 49 328 60 36 7.3
167086 12.5 18, 20 75 82 26 62 388 90 48 11.7
11.158-027-22R 15 22 97 95 33 63 457 80 49 18
11.158-027-26R 21.2 26 123 115 52 69 535 99 56 32
