Standard: EN 13411-5 Type A Formerly DIN 1142

Certification: a works certificate can be supplied upon request

  • Material: Bridge : malleable steelU-bolt : mild steel
  • Marking: According to standard
  • Finish: electro-galvanized
  • Standard: EN 13411-5
Select a row from the table below, then click the add to quote button
Rope diameter
mm
a
mm
b
mm
c
mm
d
mm
e
mm
f
mm
g
mm
Weight
kg/100pc
5 5 25 12 14 25 13 13 2
6,5 6 32 14 17 30 16 14 4
8 8 41 18 20 39 20 18 8,2
10 8 46 20 24 40 20 21 9,2
12 10 56 24 28 50 25 24 21,5
13 12 64 29 29 55 28 29 27,5
14 12 66 28 31 59 30 28 39,5
16 14 76 34 35 64 32 35 43
19 14 83 37 36 68 33 40 49
22 16 96 41 40 74 34 44 68
26 20 111 46 50 84 38 51 117
30 20 127 54 55 95 41 59 140
34 22 141 60 60 105 45 67 213
40 24 159 68 65 117 49 77 268
